Meridian SMOOTHWALL BIN - Section 7: REFERENCE; 7.3 GRAINMAX BIN SPECIFICATIONS

Revised 06.2021 7-3
Owner’s Manual: Smoothwall Bin
®
Table 7 - Western Canada
MODEL DESCRIPTION
APPROX.
BUSHELS
CUBIC
FEET
IMP. TONS
METRIC
TONNES
BIN HEIGHT
REC.
AUGER
GM2300
14’ Diameter
40° Bottom Cone
2,296 2,702 67 61 26’ 5” 46’
GM3000
15’ 6” Diameter
40° Bottom Cone
3,037 3,573 89 81 28’ 9” 53’
GM4000 3,836 4,514 112 102 33’ 9” 59’
GM5000 4,636 5,455 136 123 38’ 9” 66’
GM6000 5,434 6,394 159 145 43’ 9” 72’
GM3000
16’ Diameter
40° Bottom Cone
3,258 3,833 95 86 28’ 11” 53’
GM4000 4,109 4,835 120 109 33’ 11” 59’
GM5000 4,962 5,838 145 132 38’ 11” 66’
GM6000 5,813 6,839 170 155 43’ 11” 72’
GM5300
18’ Diameter
40° Bottom Cone
5,312 6,250 156 141 35’ 6” 59’
GM6400 6,392 7,520 188 170 40’ 6” 66’
GM7500 7,470 8,789 219 199 45’ 6” 79’
2025
20’ Diameter
40° Bottom Cone
8,028 9,445 236 214 41’ 10” 66’
2030 9,361 11,013 275 249 46’ 10” 79’
2035 10,693 12,580 314 285 51’ 10” 85’
Table 8 - Eastern Canada, Northeastern USA
MODEL DESCRIPTION
APPROX.
BUSHELS
CUBIC
FEET
IMP. TONS
METRIC
TONNES
BIN HEIGHT
REC.
AUGER
1310GM
13’ Diameter
45° Bottom Cone
1533 1816 45 41 21’ 6” 41’
1315GM 2093 2480 62 56 26’ 6” 51’
1320GM 2653 3194 78 71 31’ 6” 61’
1325GM 3212 3807 95 86 36’ 6” 71’
1330GM 3772 4471 112 101 41’ 6” 71’
1335GM 4332 5135 128 116 46’ 6” 81’
1412GM
13’ 6” Diameter
40° Bottom Cone
1881 2213 55 50 24’ 1-13/16” 51’
1420GM 2854 3358 84 76 31’ 9-13/16” 61’
1425GM 3463 4074 102 92 36’ 9-13/16” 71’
1430GM 4071 4790 120 109 41’ 9-13/16” 71’
1435GM 4680 5506 137 125 46’ 9-13/16” 79’
7.3 GRAINMAX BIN SPECIFICATIONS
