MERITECH CleanTech EVO Wall - Internal Components

41
Solutions Receptacle
Solutions Receptacle
– PCB Assy. UPX
Solutions Receptacle
– PCB Assy.
SelfCleanX
Bottle Pierce Tube
Assy. (internal to solution receptacle)
– UPX & SelfCleanX
Station Serial Label
Top Cover Screws
(solutions door must be
opened to access screws for
top cover removal)
Solutions Receptacle
Tilting Latch (both sides)
Solutions Bottle Vent Check Valve
(back side of receptacle)
Internal Components
