Merrychef eikon e4s - 21 Spare Parts

Service & Parts Manual original Instructions
Part Number 32Z3871 US
Issue 3
43
Recommended Parts List
Part
Number
Description
Qty
Per
Oven
Unit
1-10
Ovens
11-50
Ovens
51-100
Ovens
1st
Aid/To
Go Box
Service
Centre
Kit
e4s
Unique
Parts
over e4
105005 M3 CAGE NUT 10 EA 10 30 60
30Z0503 SWITCH ON/OFF ROCKER DPST 1 EA 1 2 4 1 1
30Z1177 20 AMP LITTLEFUSE FLM020 2 EA 2 6 12 2 4
30Z1178 30A FUSE HOLDER 2 EA 2 6 12 1 2
30Z1427 MAGNETRON OVERHEAT STAT 2 EA 2 6 12 1 1
30Z1430 MICROSWITCH (LARGE) 1 EA 2 6 12 1 1
30Z1459 MICROSWITCH 2 EA 1 3 6 1 4
30Z1521 e4s MOTOR SPEED CONTROLLER 1 EA 0 1 2 1 1
30Z5009
eikon TOUCH SCREEN & PCB
1 EA 1 3 6 1
30Z5011
CONTROL PCB
e4s SRB
1 EA 1 3 6 1 1
30Z5013 HT DIODE 750mA 2 EA 2 6 12 2 2 2
31Z0115 INSULATOR PAD 2 EA 2 6 12
31Z0186 SILASTIC BLACK (DOOR SEAL) TUBE 1 3 6 1 1
31Z0600 USB ADAPTOR MODULE 1 EA 1 3 6 1
31Z0620 BTS UI SRB CABLE (WHITE) 1 EA 1 3 6 1 1
31Z1252 BOLT M4 X 10 HEX HD FLANGE SS 8 EA 8 24 48 8
31Z1255 PG21 CABLE GLAND BLACK 1 EA 1 3 6
31Z1256 PG21 CABLE GLAND NUT 1 EA 1 3 6
31Z1259 SHEET COVER CAP 12MM DIA 4 EA 4 12 24
32Z4028 HALF SIZE GASTRONOM DISH 1 EA 1 3 6
32Z7075
PERSONALITY MODULE
SRB e4s
1 EA 1 3 6 1 1
32Z7076
PERSONALITY MODULE
QTS e4s
1 EA 1 3 6 1 1
6004011 RUBBER FOOT 0 40 X 25 1 EA 1 3 6
DR0006 REED SWITCH 1 EA 1 3 6 1 1
DR0007 MERRYCHEF BADGE 1 EA 1 3 6
DR0008 MERRYCHEF BADGE SLIDER 1 EA 1 3 6
DR0009 MERRYCHEF BADGE GUIDE 2 EA 2 6 12
DR0011 TOUCHSCREEN OVERLAY 1 EA 1 3 6 1
DR0021 HARMONISED SPEAKER 1 EA 1 3 6 1
DR0030 HANDLE SPACER 2 EA 2 6 12
DR0047 MERRYCHEF BADGE SEAL 1 EA 1 3 6
DR0060 STIRRER COVER - CERAMIC 2 EA 2 6 12 2 2
DR0079 OVEN TEMP STAT 1 EA 1 3 6 1 1
DV0168VIT DOOR CHOKE PRESSED VITREOUS 1 EA 1 3 6
DV0187 TOP PANEL (PRESSED) 1 EA 0 1 2
DV0202 CERAMIC PLATE RETAINER 4 EA 0 1 2 4
DV0370 LOWER IMPINGER HANDLE 1 EA 1 3 6 1
DV0403 CAST REAR DUCTING LH 1 EA 1 3 6
DV0431 DOOR HANDLE 1 EA 1 3 6
DV0437 LOWER FASCIA FINISHED 1 EA 1 3 6
DV0452 CAPACITOR CLIP 2 EA 0 1 2
DV0692 SEAL - CERAMIC COVER 2 EA 2 6 12 2 2
DV0714 e4s WIRE RACK 1 EA 0 1 2 1
DV0773 CAVITY HOT BOX FINISHED 1 EA 1 3 6 1
DV0815 e4s CAVITY THERMOCOUPLE 1 EA 1 3 6 1 1 1
DV0825 e4s CAST RH DUCT MODIFIED 1 EA 1 3 6 1
DV0838 CONTROL PANEL e4/e4s 1 EA 0 1 2
DV0840 e4s RH SIDE PANEL 1 EA 0 1 2 1
DV0841 e4s LH SIDE PANEL 1 EA 0 1 2 1
P30Z1415 MAGNETRON 2M303H 2 EA 0 1 2 1 2
PSA1215 e4s DOOR ASSEMBLY (COMPLETE) 1 EA 1 3 6 1
PSA1240 e4s UPPER IMPINGER PLATE 1 EA 0 1 2 1
PSA1241 e4s HOT AIR MOTOR ASSY KIT 1 EA 1 3 6 1 1
Merrychef eikon e4s Oven
Recommended Minimum Stock Holding & Service Kits
SPARES &
REPLACEMENT
21 SPARE PARTS
Parts list & recommended minimum stock holding & Service Kits
