Merrychef eikon e4s - Page 44

44
Service & Parts Manual original Instructions
P
art Number 32Z3871 US
Issue 3
Recommended Parts List
Part
Number
Description
Qty
Per
Oven
Unit
1-10
Ovens
11-50
Ovens
51-100
Ovens
1st
Aid/To
Go Box
Service
Centre
Kit
e4s
Unique
Parts
over e4
PSA1242 e4s HEATER ASSEMBLY KIT 1 EA 1 3 6 1 1
PSA1243 e4s GASKET KIT 1 EA 1 3 6 1 1
PSA2144 DOOR SKIN ASSY e4 1 EA 0 1 2
PSA2191 e4s IMPINGER PLATE LOWER 1 EA 1 3 6 1
PSA2195 e4s COOLING FAN ASSEMBLY 1 EA 0 1 2 1 1
PSA2197 e4s DOOR+CHOKE ASSY 1 EA 0 1 2 1
PSA2201 e4s WAVEGUIDE ASSY 2 EA 1 3 6 2
PSA288 STIRRER MOTOR ASSY (PINNED) 2 EA 0 1 2 2
PSA291 STIRRER ASSY (PINNED) 2 EA 0 1 2 2
PSA3113 DOOR SEAL 1 EA 1 3 6 1 1
PSR e4s EIKON DOOR HINGE KIT EA 1 3 6 1
PSR102 EIKON M/SWITCH BRACKET KIT EA 1 3 6 1
SA3114 e4s CAVITY ASSY 1 EA 0 1 2
SA3127 AIR FILTER ASSY e4 1 EA 1 3 6 1 1
SA3132 e4s CAVITY INNER STEAM PIPE 1 EA 1 3 6 1
SA3134 REAR PANEL WELDED ASSY e4s 1 EA 1 3 6 1
SA3136 CAVITY WRAP KIT 1 EA 0 1 2 1
SA3150 e4s LOWER CAT ASSY 1 EA 0 1 2 1
SA3151 e4s UPPER CAT ASSY 1 EA 0 1 2 1
SA3153 e4s AIR DIFFUSER ASSY 1 EA 1 3 6 1 1 1
eikon e4s 230Volts 50Hz - UK/EU - Single Phase - Unique Parts
30Z0231 FUSEHOLDER 1in (13A) 3 EA 3 9 18 3 6
30Z0456 FUSE 1in 13A HRC 3 EA 3 9 18 3 6
30Z1425 TRANSFORMER 240V 50/60Hz 1 EA 1 3 6 1 2
30Z1431 1.2uF 2500V CAPACITOR 2 EA 2 6 12 2 2 2
30Z1488 e4s MAINS FILTER 1 EA 1 3 6 1 2 1
P30Z1413 230V 50Hz TRANSFORMER 2 EA 2 6 12 2
POWER SUPPLY LEAD (UK) 3C 1 EA 1 3 6
eikon e4s 230Volts 50Hz - UK/EU - Twin Phase - Unique Parts
30Z0231 FUSEHOLDER 1in (13A) 3 EA 3 9 18 3 6
30Z0456 FUSE 1in 13A HRC 3 EA 3 9 18 3 6
30Z1425 TRANSFORMER 240V 50/60Hz 1 EA 1 3 6 1 2
30Z1431 1.2uF 2500V CAPACITOR 2 EA 2 6 12 2 2 2
30Z1488 e4s MAINS FILTER 1 EA 1 3 6 1 2 1
P30Z1413 230V 50Hz TRANSFORMER 2 EA 2 6 12 2
SA2209 e4s 2P PLUG - 1P LEAD HC 1 EA 1 3 6
30Z0231 FUSEHOLDER 1in (13A) 3 EA 3 9 18 3 6
30Z0456 FUSE 1in 13A HRC 3 EA 3 9 18 3 6
30Z1425 TRANSFORMER 240V 50/60Hz 1 EA 1 3 6 1 2
30Z1431 1.2uF 2500V CAPACITOR 2 EA 2 6 12 2 2
30Z1534 e4s MAINS FILTER 20A 2 EA 2 6 12 1 2 1
P30Z1413 230V 50Hz TRANSFORMER 2 EA 2 6 12 2
SR233 e4s MAINS CABLE AZ 5P 1 EA 1 3 6
Merrychef eikon e4s Oven
Recommended Minimum Stock Holding & Service Kits
eikon e4s 230Volts 50Hz - AZ - Unique Parts
SPARES &
REPLACEMENT
