Merrychef eikon e4s - Page 45

Service & Parts Manual original Instructions
Part Number 32Z3871 US
Issue 3
45
Recommended Parts List
Part
Number
Description
Qty
Per
Oven
Unit
1-10
Ovens
11-50
Ovens
51-100
Ovens
1st
Aid/To
Go Box
Service
Centre
Kit
e4s
Unique
Parts
over e4
30Z0231 FUSEHOLDER 1in (13A) 3 EA 3 9 18 3 6
30Z0456 FUSE 1in 13A HRC 3 EA 3 9 18 3 6
30Z1425 TRANSFORMER 240V 50/60Hz 1 EA 1 3 6 1 2
30Z1331 1.00uF 2500V CAPACITOR 2 EA 2 6 12 2 2
30Z1488 e4s MAINS FILTER 1 EA 1 3 6 1 2 1
P30Z1230 60HZ TRANS MULTI TAP 2 EA 2 6 12 2
POWER SUPPLY LEAD HE (EU) 1 EA 1 3 6
30Z0285 FUSEHOLDER 1 1/4in (13A) 3 EA 3 9 18 3 6
30Z1331 1.00uF 2500V CAPACITOR 2 EA 2 6 12 2 2
30Z1439 OMRON RELAY 12V 2 EA 2 6 12 1 2
30Z1455 TRANSFORMER LV CLASS 2 1 EA 1 3 6 1 2
30Z1488 e4s MAINS FILTER 1 EA 1 3 6 1 2 1
30Z1507 e4s USA 12A FUSE SLOW/B 3 EA 3 9 18 3 6 3
PLUG & LEAD ASSY (SUBWAY) 1 EA 1 3 6
P30Z1230 60HZ TRANS MULTI TAP 2 EA 2 6 12 2
Merrychef eikon e4s Oven
Recommended Minimum Stock Holding & Service Kits
eikon e4s 220Volts 60Hz - SA - Unique Parts
eikon e4s 208V & 240V 60Hz - USA - Unique Parts
FAULT FINDING
