31
Solution
Fabric Jams
Machine Does Not Operate
* Check for tangled or caught thread.
* Compress thick layers of fabric with conventional machine before sewing
with cover stitch.
* Connect machine to power source correctly.
Problem
25. SPECIFICATIONS
Sewing speed
Stitch length
Differential feed ratio
Cover stitch width
Needle bar stroke
Presser foot rise
Needles
Number of needles
Number of threads
Maximum 1300 stitches/min
1.0 - 5.0 mm
1:0.6 - 1:2
Coverstitch: 2.8 - 5.6 mm
27 mm
4.5 mm
ELx705 size: #14/90, #12/80
1, 2, 3
2, 3, 4
26. MACHINE DIMENSIONS
Width
Length
Height
372mm/ 412 mm
293mm
296 mm/ 354mm
Weight
7.7 kg
We reserve the right to change the machine equipment and the assortment of accessories without prior notice,
or make modification cations to the performance or design. Such modification cations, however, will always be
to the benefit of the user and the product.
