21
4 AP822 Mounting
AP822 ships with several different mounting bracket components that allow for a variety of
mounting options. You can mount an AP822 in any of the following ways:
You can mount an AP822 in any of the following ways:
“Horizontally on a Shelf” on page 21
“Vertically on a Wall” on page 22
“Box Mount” on page 26
“Below a Standard Suspended Ceiling” on page 27
“Above a Standard Suspended Ceiling” on page 33
Horizontally on a Shelf
When mounting an AP822 horizontally, place it on the desired surface and connect the power
and network cables (G1 Ethernet Port is also used a PoE input). Optional stands (MNT-FEET-
SET-X5) can be applied underneath to raise AP822 for additional cabling space.
Read and follow the regulatory instructions in Appendix A before installing and operating AP822.
