28
AP Installation over Standard 9/16” or 15/16” T-Bar
The accessory required for such installation is listed below:
1. Orient T-Bar adapter/Wall mount adapter with the back of the AP, so that the 2 mounting
pins align with the receiving slots.
2. Slide the adapter plate from left to right until the locking mechanism “clicks” into place.
Item Model Number Quantity
15/16” T-bar & wall-mount combo
adapter (650-00232)
1
9/16” T-bar adapter (650-00233) 1
