METEK GmbH uSonic-2
2 Installation
Please check delivery for completeness and good condition before starting
installation. Strong damages of the package may be caused by improper
transport. In this case a deformation of the sensor head is possible and a new
calibration may be required.
Before starting final installation at the measuring site it is recommended to
check functionality of the complete system, including peripheral devices and
power supply.
Avoid mechanical forces and impacts while transport and mounting the
sensor head. The sensor head may be deformed and a malfunction will
appear. In this case a new calibration may be required. Please see Appendix
B in this document.
Please ship and transport the sensor head always in the original
transportation box!
When connecting the system to a power supply and external devices via the
serial or analog ports make sure that the pinning is correctly assigned as
given by the table on page 12.
2.1 Mounting the uSonic-2
The uSonic-2 can be mounted on a pipe with an inside diameter of 34mm.
Please regard that the cable has to be installed inside of this tube.
Alternatively a pipe clamp can be used. Contact METEK GmbH about
additional equipment and adapters for masts.
Mount the uSonic-2 as shown at following illustrations and check the vertical
alignment to get exact measurements.
We recommend keeping a distance of at least 0.3 m to big adjacent
structures (walls) of the measuring volume to avoid that the sonic signal is
disturbed or reflected.
