• Follow the instructions displayed in the teach dialog, positioning your sensor in the light, the
dark, and finally in the light again.
• Once the teach is complete press the Done button to finish the edge sensor calibration
procedure.
The system should not be prepared to enter edge positions with the Auto Enter and Manual Edge probe
mode.
Adding Additional Magnifications
In some cases more than one lens(magnification) will be used with a given measuring system. Each one
of these lenses can be calibrated independently for the storage and recall of taught edge values, lens to
crosshair offsets, and distance calibration(edge correction).
New magnifications are added and configured via the Optical Edge setup screen
Mx Button-->Setup-->Optical Edge
Add a new magnification by pressing “+” button(softkey 1).
Screenshot
Name the new magnification and press OK. You should now be viewing the settings for the new
magnification.
Mag Menu Item
Description
Name
Displays the name assigned to the current magnification. Press to rename
the magnification.
(X/Y)Edge to Xhair
Offset
Press to Enter the X and Y offset between the current optical edge sensor
position and the current position of the screen crosshair.
