4.4.2 Menu Items and Values
The table below lists all the menu items and their possible values in the ‘Printer
Setup Procedure’.
Item#
(Flashes)
Item Name Description Possible Values
1
Media Type Sets printing for either direct
thermal or thermal transfer
stock.
*DIRECT THERMAL
THERMAL TRANSFER
2
Sensor Type Select the sensor type that
matches your label stock.
*EDGE: (Gaps in media)
(REFL) REFLECTIVE: (Black
stripes)
(CONT) CONTINUOUS: (No
sensing)
3
Present
Sensor
Enables/Disables optional
Present Sensor
*NO or YES
4
Cutter
Equipped
Enables/Disables optional
Cutter
*NO or YES
5
SOP Adjust Allows fine-tuning of the
starting print position on
each label.
0 – 255; default = *128
0 = close to edge
255 = furthest from edge
6
Present
Adjust
Adjusts the present distance. 0 – 255; default = *128
0 = close to edge
255 = furthest from edge
7
Baud Rate Serial port baud rate. 600 to 38.4k; default = *9600
8
Data, Parity Data word length and parity. *8,N or 7,E
9
Control
Codes
Allows code selection listed
in Programmer’s manual.
(STD) *STANDARD CODES
(ALT) ALTERNATE CODES
10
CONT.
Form Length
Sets label length for
continuous media.
0 – 9999; default = *100
11
OOS
MAXVOLT
Sets the sensor reading that
can indicate OOS, (out of
stock condition).
0 – 16; default = *2
Units: 0.1 volt
12
TOF Gain Sets TOF Gain value. 0 – 15; default = *10
13
TOF Delta Sets minimum change in the
sensor reading required to
recognize a “Gap” or Mark”.
0 – 50; default = *10
Units: 0.1 volt
14
TOF Low Sets the minimum sensor
reading for paper (EDGE) or
mark (Reflective).
0 – 50; default = *0
Units: 0.1 volt
15
Label Width Sets the label width. 75 – 410; default = *410
16
Scalable
Font Cache
Sets the number of 1K
blocks allocated for scaleable
fonts.
0 – 128; default = *64
17
Internal
Module
Sets the number of 1K
blocks allocated for the
internal RAM module.
0 – 128; default = *128
* = Default Setting
