Metra Electronics 99-4644 - Chevrolet Citation;Corvette Dash Disassembly; Chevrolet Citation II 1985 Disassembly; Chevrolet Corvette 1984-1989 Disassembly; Chevrolet Corvette 1997-2004 Disassembly

1. Remove(2)screwsfromthebottomsteering
columntrimpanelandremove.(FigureA)
2. Remove(6)screwsfromthedashtrimbezel,
disconnectthewiringandremove.(FigureA)
3. Removethehardwaresecuringthefactory
mountingbracketstothefactoryradio.
(FigureB)
4. Removeandretainthebrackets.

Chevrolet Citation II
1985
Chevrolet Corvette
1997-2004
Chevrolet Corvette
1984-1989
1. Remove(7)screwsfromthedashtrimbezel.
(FigureA)
2. Movethegearshiftertothelowestposition.
3. Pulltherightedgeofthebezelforward,unhookthe
leftsideandremove.
4. Removethehardwaresecuringthefactory
mountingbracketstothefactoryradio.
(FigureB)
5. Removeandretainthebrackets.

1. Pryoutontheridecontrolswitchanddisconnect
thewiring.
2. Unsnaptheswitchtrimandremove(2)10mmhex-
headboltsexposed.
3. Openthecenterconsoledoor,remove(4)screws
fromtheinnerhingeandremovethedoor.
4. Opentheashtrayandremove(1)screwexposed.
Removetheashtrayand(1)screwexposed.
5. Unclipthesmallgrilletotheleftoftheignition
switchandremove(1)screwexposed.
6. Unclipthebaseoftheradiotrimbezelandremove.
(FigureA)
7. LocateBracketSet#10.(FigureB)

(Figure A) (Figure B)
(S-10application
shownasexample)
(Figure A) (Figure B)
(S-10application
shownasexample)
(Figure A) (Figure B)
Dash Disassembly 99-4644
