Metra Electronics 99-4644 - Oldsmobile Dash Disassembly Procedures; Oldsmobile Ninety-Eight;Delta 88 1984-1988 Disassembly; Oldsmobile Achieva 1992-1995 Disassembly; Oldsmobile Cutlass Calais 1984-1991 Disassembly

1. Placethegearshifterinlowandremovethe
rubbertrimbootfromthesteeringcolumn.
2. Remove(2)Phillipsscrewsfromtheradiotrimbezel.
3. Unhooktheashtray/lightwiringterminaland
removethetrimbezel.(FigureA)
4. Removethehardwaresecuringthefactorymounting
bracketstothefactoryradio.(FigureB)
5. Removeandretainthebrackets.

Oldsmobile Ninety-Eight
1984-1990/Delta 88
1986-1988
Oldsmobile Cutlass Calais
1984-1991
Oldsmobile Achieva
1992-1995
1. Remove(4)screwsfromthetopedgeofthedash
trimbezel.(FigureA)
2. Remove(2)screwsfromthebottomedgeofthe
bezel.(FigureA)
3. UnsnaptheA/Cducts,disconnectthelightswitch
andremovethebezel.
4. Removethehardwaresecuringthefactorymounting
bracketstothefactoryradio.(FigureB)
5. Removeandretainthebrackets.

1. Removetheconsole/gloveboxassemblyand(3)
screwsbelowthebox.
2. Liftuptheparkingbraketrimandremove(2)
screwsfromthegearshiftertrim.(FigureA)
3. Removetheashtrayfromthegearshifterareaand
(2)7mmscrewsexposed.
4. Usingascrewdriver,depresstheretainertabson
thedashashtray,pulltheashtrayoutandremove(2)
7mmhex-headscrewsfromtheashtraybracket.
5. Removethehardwaresecuringthefactorymounting
bracketstothefactoryradio.(FigureB)
6. Removeandretainthebrackets.

(Figure A) (Figure B)
(S-10application
shownasexample)
(Figure A) (Figure B)
(S-10application
shownasexample)
(Figure A) (Figure B)
(S-10application
shownasexample)
Dash Disassembly 99-4644
