Metra Electronics 99-4644 - Pontiac Grand Am Dash Disassembly; Pontiac Grand Am 1985-1991 Disassembly; Pontiac Grand Am 1992-1995 Disassembly; Pontiac Grand Am 1996-1998 Disassembly

1. Carefullyunsnapthefrontedgeofthegearshifter
consolepanel.
2. Unsnapandremovethedashtrimbezel.(FigureA)
3. Removethehardwaresecuringthefactory
mountingbracketstothefactoryradio.
(FigureB)
4. Removeandretainthebrackets.

Pontiac Grand Am
1985-1991
Pontiac Grand Am
1996-1998
Pontiac Grand Am
1992-1995
1. Remove(6)7mmhex-headscrewsfromthedriver’s
sidekneebolsterpanelandlowerthepanel.
2. Remove(4)Phillipsscrewsfromtheglovebox/
cupholderassembly.
3. Remove(1)7mmhex-headscrewfromtheleft
cornerofthedashtrimbezel.(FigureA)
4. Loosen(2)10mmnutsfromthetopofthefactory
radio,slidetheradiooutanddisconnectthewiring.
(FigureA)
5. Removethehardwaresecuringthefactorymounting
bracketstothefactoryradio.(FigureB)
6. Removeandretainthebrackets.

1. Remove(2)Phillipsscrewsfromthepocket.
2. Remove(2)Phillipsscrewsabovetheinstrument
cluster.(FigureA)
3. Unclipthedashtrimbezelandremove.
4. Remove(3)7mmhex-headscrewssecuringthe
factoryradioanddisconnectthewiring.
5. LocateBracketSet#9.(FigureB)

(Figure A) (Figure B)
(S-10application
shownasexample)
(Figure A) (Figure B)
(S-10application
shownasexample)
(Figure A) (Figure B)
Dash Disassembly 99-4644
