Metra Electronics 99-4644 - DIN Radio Provision

DIN radio provision
Kit Assembly 99-4644
(Figure B)(Figure A)
1. Chooseafaceplate(accordingtothedesiredinstallationdepth)andsnapitonto
thefrontoftheradiohousingandsecurewith(4)hex-headscrews.(FigureA)
2. Securemountingbracketstotheradiohousingwiththesuppliedcarriagebolts
andnuts.(FigureA)
3. Thensnaptherearsupporttrayontothebackoftheradiohousing.(FigureA)
4. SildetheDINcageintothekitandsecurebybendingthemetallockingtabs.
(FigureB)
5. Locatethefactorywiringharnessandantennapluginthedash.Metra
recommendsusingthepropermatingadapterfromMetraorAXXESS.Re-
connectthenegativebatteryterminalandtesttheradioforproperoperation
6. Reassembledashinreverseorderofdisassemblyusingscrewspreviously
removed.(FigureB)
