Metra Electronics 99-4644 - Chevrolet Nova;S-10 Dash Disassembly; Chevrolet Nova 1985-1988 Disassembly; Chevrolet S-10 Pickup;Blazer 1982-1985 Disassembly; Chevrolet S-10 Pickup;Blazer 1986-1994 Disassembly

1. Removetheashtrayand(2)screwsfromthe
ashtraybracket.(FigureA)
2. Remove(2)screwsabovetheradioopeningand
removetheradiotrimbezel.(FigureA)
3. CutandremoveallmountingtabsonBracket#1
EXCEPTtabs“B”.(FigureB)
Note: Identify mounting tabs by the stamped letter
on the back of each tab.

Chevrolet Nova
1985-1988
Chevrolet S-10 Pickup
1986-1993/S-10 Blazer
1986-1994, GMC S-15
Pickup 1986-1990/S-15
Jimmy 1986-1994/Sonoma
1991-1993, Oldsmobile
Bravada 1991-1994
Chevrolet S-10 Pickup/S-10
Blazer 1982-1985
GMC S-15 Pickup/S-15
Jimmy 1982-1985
1. Remove(4)star-drivescrewsfromthecornersof
thedashtrimbezel.(FigureA)
2. Remove(1)star-drivescrewfromthelower-right
corneroftheinstrumentclusterpanelandremove
thedashtrimbezel.
3. CutandremoveallmountingtabsonBracket#5
EXCEPTtabs“B”.(FigureB)
Note: Identify mounting tabs by the stamped letter
on the back of each tab.

1. Removetheashtrayand(1)screwinsidethe
ashtraycavity.
2. Openthegloveboxandremove(2)screws
exposedontheedgeofthedashtrimbezel.
(FigureA)
3. LocateBracket#(L)S-10andtherightBracket
fromBracketSet#5.
4. Cutandremoveallmountingtabsontheright
BracketEXCEPTtoptab“B”.(FigureB)
Note: Identify mounting tabs by the stamped letter
on the back of each tab.

(Figure A) (Figure B) (Figure A) (Figure B) (Figure A) (Figure B)
“B”
“B”
“B”
“B”
Dash Disassembly 99-4644
