Metra Electronics 99-4644 - Cadillac Dash Disassembly Procedures; Cadillac Deville;Fleetwood 1985-1995 Disassembly; Cadillac Eldorado;Seville 1984-1991 Disassembly; Cadillac Escalade;Avalanche;Yukon 1995-2002 Disassembly

1. Remove(2)screwsfromthetopoftheradio
trimbezel.
2. Pulloutonthetopedgeofthebezelandliftup
toremove.(FigureA)
3. Removethehardwaresecuringthefactory
mountingbracketstothefactoryradio.
(FigureB)
4. Removeandretainthebrackets.

Cadillac Deville 1985-1995
Fleetwood 1985-1992
Cadillac Escalade, Escalade
EXT/Chevrolet Avalanche,
C-K Pickup, Silverado,
Suburban, Tahoe/GMC C-K
Pickup, Sierra, Suburban,
Yukon 1995-2002
Cadillac Eldorado/Seville
1984-1991
1. Remove(2)PhillipsscrewsabovetheA/Cvents.
(FigureA)
2. Pulloutonthetopedgeofthedashtrimbezel
unhookthebottomedgeandremove.
3. Removethehardwaresecuringthefactory
mountingbracketstothefactoryradio.
(FigureB)
4. Removeandretainthebrackets.
1. Removethesteeringcolumnfillerpanelandthe
ashtray.(FigureA)
2. Unclipthedashtrimbezelandremove.
3. Usingasmallflat-bladescrewdriver,press
downontheouterclipsofthefactoryradio
(orpocket).
4. Disconnectthewiringandremovetheradio.
Locate Bracket Set #8. (Figure B)
(Figure A) (Figure B)
(S-10application
shownasexample)
(Figure A) (Figure B)
(S-10application
shownasexample)
(Figure A) (Figure B)
Dash Disassembly 99-4644
