Metra Electronics 99-4644 - Buick Skylark Dash Disassembly; Buick Skylark 1983-1986 Disassembly; Buick Skylark 1987-1989 Disassembly; Buick Skylark 1990-1995 Disassembly

1. Remove(4)screwsfromthetopedgeofthe
instrumentpanel.(FigureA)
2. Remove(1)screwfromthebottom-leftcornerof
thepanel.(FigureA)
3. Remove(2)screwsfromthesteeringcolumntrim
andremovethetrim.
4. Pullupandoutonthedashtrimbezelandremove.
5. Removethehardwaresecuringthefactory
mountingbracketstothefactoryradio.
(FigureB)
6. Removeandretainthebrackets.

Buick Skylark 1983-1986
Buick Skylark 1990-1995Buick Skylark
1987-1989
1. Unsnapthegearshifterbezelfromthebase
oftheconsole.
2. Remove(2)screwssecuringthebottomofthe
dashtrimbezelandremovethebezel.(FigureA)
3. Removethehardwaresecuringthefactory
mountingbracketstothefactoryradio.
(FigureB)
4. Removeandretainthebrackets.
1. Pulloutontheashtrayandremove(2)screws
exposedintheashtraycavity.
2. Remove(2)screwssecuringthefrontofthe
ashtrayandlowersectionofthedashtrimbezel.
(FigureA)
3. Usingapanelremovaltool,gentlypryoutonthe
trimbezelandremove.
4. Remove(2)nutsfromthebottomofthefactory
radioanddisconnectthewiring.
5. Removethehardwaresecuringthefactory
mountingbracketstothefactoryradio.
(FigureB)
6. Removeandretainthebrackets.

(Figure A) (Figure B)
(S-10application
shownasexample)
(Figure A) (Figure B)
(S-10application
shownasexample)
(Figure A) (Figure B)
(S-10application
shownasexample)
Dash Disassembly 99-4644
