1. Remove(2)screwsfromthe
driver’ssideservicepaneland
unclipthepanel.
2. Pryoffthetrimpiecelocated
abovethegloveboxandremove
(1)screw.
3. Remove(3)screwsfromthe
topedgeofthedashtrimbezel.
(FigureA)
4. Remove(1)screwfromthe
lower-leftcorneroftheglovebox
and(1)screwfromtheparking
brakerelease.
5. Removethedashtrimbezel.
6. Cutandremoveallmountingtabs
onBracket#4EXCEPTtabs“B”.
(FigureB)
Note: Identify mounting tabs
by the stamped letter on the back
of each tab.
Buick Roadmaster 1991-1994
Chevrolet Caprice 1991-1993
(Figure A)
(Figure B)
“B”
1. Removethegloveboxbyremoving
thedoorstrapwireclipand(4)
screws.(FigureA)
2. Remove(2)screwsbelowthe
cigarettelighterhousingand(3)
screwsbelowthesteeringcolumn.
(FigureA)
3. Remove(1)screwfromthetop-left
ofthefactoryradioandunclipthe
dashtrimbezel.(FigureA)
4. Removethehardwaresecuringthe
factorymountingbracketstothe
factoryradio.(FigureB)
5. Removeandretainthebrackets.
Buick Syhawk 1982-1989/Oldsmobile
Firenza 1982-1988
(Figure A)
(Figure B)
(S-10application
shownasexample)
Dash Disassembly 99-4644
