Metra Electronics 99-4644 - Chevrolet El Camino;Express;Lumina Dash Disassembly; Chevrolet El Camino 1986-1988 Disassembly; Chevrolet Express;GMC Savana 1996-2000 Disassembly; Chevrolet Lumina 1990-1994 Disassembly

1. Remove(4)screwsfromthedashtrimbezel.
(FigureA)
2. Removethebezelanddisconnectthecigarette
lighterwiring.
3. CutandremoveallmountingtabsonBracket#2
EXCEPTtabs“C”.(FigureB)
Note: Identify mounting tabs by the stamped letter
on the back of each tab.

Chevrolet El Camino
1986-1987, Monte Carlo
1986-1988
Chevrolet Lumina
1990-1994
Chevrolet Express/GMC
Savana 1996-2000
1. Uncliptheplastictrimpiecelocatedbelowthe
steeringcolumn.
2. Unclipthedashtrimbezel.Pullthebezeloverthe
steeringcolumnanddisconnectthewiring.
(FigureA)
3. Usingaflat-bladescrewdriver,pressdownonthe
outsideclipsofthefactoryradioandremove.
4. LocateBracketSet#8.(FigureB)

1. Remove(2)screwsfromthelowersteering
columnpanel.
2. Pullthepaneldowntoaccessthebottomportion
oftheradiotrimbezel.(FigureA)
3. Pullthetopandbottomedgesofthebezel.
(FigureA)
4. CutandremoveallmountingtabsonBracket#5
EXCEPTtabs“A”.(FigureB)
Note: Identify mounting tabs by the stamped letter
on the back of each tab.

(Figure A) (Figure B) (Figure A) (Figure B) (Figure A) (Figure B)
“C”
“C”
“A”
“A”
“A”
“A”
Dash Disassembly 99-4644
