Metra Electronics 99-4644 - Chevrolet Astro;GMC Safari Dash Disassembly; Chevrolet Astro;GMC Safari 1985-1989 Disassembly; Chevrolet Astro;GMC Safari 1990-1995 Disassembly; Chevrolet Astro;GMC Safari 1996-2005 Disassembly

1. Remove(3)Phillipsscrewsfromthetopportionof
thedashtrimbezel.(FigureA)
2. Openthegloveboxandremove(2)10mmbolts
fromtheloweredgeofthetrimbezel.(FigureA)
3. Pulltheconsoletrimforwardandremove(2)7mm
boltsexposed.
4. Gentlyunclipandremovethetrimbezel.Remove
(2)7mmscrewsfromthefactoryradioand
disconnectthewiring.
5. CutandremoveallmountingtabsonBracket#3
EXCEPTtabs“A”.(FigureA)
Note: Identify mounting tabs by the stamped letter
on the back of each tab.

Chevrolet Astro/GMC
Safari 1985-1989
Chevrolet Astro/GMC
Safari 1996-2005
Chevrolet Astro/GMC
Safari 1990-1995
1. Remove(2)screwsfromthebottomofthedash
trimbezel.(FigureA)
2. Gentlyunclipandremovethebezel.
3. Remove(4)screwsfromthefactoryradioand
disconnectthewiring.
4. CutandremoveallmountingtabsonBracket#1
EXCEPTtabs“A”.(FigureB)
Note: Identify mounting tabs by the stamped letter
on the back of each tab.

1. Placethegearselectorinitslowestposition.
2. Uncliptheperimeterofthedashtrimbezel.
(FigureA)
3. DisconnecttherearA/Ccontrolharnessandthe
headlightswitchfromthebackofthedashtrim
bezelandremovethebezel.
4. Usingaflat-bladescrewdriver,pressdownonthe
outsideclipsofthefactoryradioandremove.
5. LocateBracketSet#8.(FigureB)

(Figure A) (Figure B) (Figure A) (Figure B) (Figure A) (Figure B)
“A”
“A”
“A”
Dash Disassembly 99-4644
