INST99-5722
KIT ASSEMBLY
ISO DDIN radio provision
1. Cut and remove the center bar from the
radio/display trim panel .
(Figure A)
2. Attach the
radio brackets to the inside
edge of the radio/display trim panel .
(Figure B)
3. Slide the radio into the bracket/panel
assembly and secure it using the screws
supplied with the radio. (Figure C)
4. Attach the ISO DDIN trim plate onto the
completed assembly. (Figure C)
Continue to Axxess
Interface Installation
(Figure A) (Figure B) (Figure C)
Remove
shaded area
