8
AXXESS INTERFACE INSTALLATION
INTERFACE FEATURES
INTERFACE COMPONENTS
• Axxess interface (built into the touchscreen display)
• 5722 harness
• 16-pin harness with stripped leads
• 4-pin harness with yellow RCA jacks
• Female 3.5mm jack with two loose wires
TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell caps, etc.)
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Retains SYNC
• Retains the factory AUX-IN jack
• Provides an aftermarket backup camera input
• Can be used in both amplified and non-amplified models (excluding SONY)
• Retains balance and fade (excluding SONY)
• Micro “B” USB updatable
Connections to be made .........................................................................................................9-12
Installing the interface ............................................................................................................... 12
Initializing the interface ..............................................................................................................13
Final assembly .............................................................................................................................13
Extra Settings ...............................................................................................................................13
Touchscreen display operation ..............................................................................................13-14
Steering wheel control settings ............................................................................................15-16
TABLE OF CONTENTS
