Metra Electronics 99-5810 - Kit Assembly for DIN Head Unit; Mounting DIN Cage; Installing Aftermarket Head Unit

2
99-5810 KIT ASSEMBLY
B
A
DIN HEAD UNIT PROVISION WITH POCKET
Slide the DIN cage into the Radio
Housing and secure by bending
the metal locking tabs down.
(Figure A)
1
Slide the after-market head unit
into the cage and secure. (Figure B)
2
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
