Metra Electronics 99-5810 - Kit Assembly for ISO DIN Head Unit; Attaching ISO Brackets; Securing Head Unit and Trim Plate

3
99-5810 KIT ASSEMBLY
B
A
ISO DIN HEAD UNIT PROVISION WITH POCKET
Mount the ISO Brackets to the head
unit with the screws supplied with
the unit.
(Figure A)
1
Slide the head unit into the radio
opening until the side clips engage.
(Figure B)
2
Snap the Trim plate into the Radio
Housing.
(Figure B)
3
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
