1.800.221.0932
|
MetraOnline.com
6
AXXESS INTERFACE INSTALLATION
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape • Wire cutter • Zip ties
TOOLS REQUIRED
INTERFACE FEATURES
INTERFACE COMPONENTS
• Axxess interface (built into the touchscreen display)
• 5839 harness
• 16-pin harness with stripped leads
• 4-pin harness with yellow RCA jacks
• Female 3.5mm jack with stripped leads
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Retains SYNC
• Retains the factory AUX-IN jack
• Provides an aftermarket backup camera input
• Can be used in both amplified and non-amplified models
• Retains balance and fade
• Micro-B USB updatable
Connections ...........................................................................................................................................7-8
Installation ...............................................................................................................................................9
Programming ...........................................................................................................................................9
Extra features (SYNC)............................................................................................................................. 10
Touchscreen display operation ..........................................................................................................11-12
Steering wheel control settings .......................................................................................................13-14
Troubleshooting ......................................................................................................................................14
TABLE OF CONTENTS
