CONNECTIONS
From the 16-pin harness with stripped leads to the aftermarket radio:
• Connect the Red wire to the accessory wire.
• If the vehicle is equipped with a Shaker/Shaker-Pro sound system or NAV, connect the Blue/
White wire to the amp turn on wire. This wire must be connected to hear sound from the
factory amplifier.
• If the aftermarket radio has an illumination wire, connect the Orange/White wire to it.
•
If the aftermarket radio has a mute wire and the vehicle is equipped with SYNC, connect the
Brown wire to it. If the mute wire is not connected, the radio will turn off when SYNC is activated.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
The following (3) wires are only for multimedia/navigation radios that require these wires.
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Green/Purple wire to the reverse wire.
• Connect the Light Green wire to the parking brake wire
• Tape off and disregard the following (4) wires, they will not be used in this application:
Green, Green/Black, Purple, Purple/Black
From the 5839 harness to the aftermarket radio:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• Connect the Blue wire to the power antenna wire.
• If the vehicle is equipped with NAV, connect the Blue/White wire with a red connector to the
amp turn on wire. This wire must be connected to hear sound from the factory amplifier.
• Connect the Green wire to the left rear positive speaker output.
• Connect the Green/Black wire to the left rear negative speaker output.
• Connect the Purple wire to the right rear positive speaker output.
• Connect the Purple/Black wire to the right rear negative output.
• For models
with
SYNC: Connect the Red and White RCA jacks labeled “RSE/SYNC/SAT”, to the
audio AUX-IN jacks. Disregard the Red and White RCA jacks labeled “FROM 3.5”, they will not
be used in this application.
• For models
without
SYNC: Connect the Red and White RCA jacks labeled “FROM 3.5”, to the
audio AUX-IN jacks. Disregard the Red and White RCA jacks labeled “RSE/SYNC/SAT”, they
will not be used in this application.
• Disregard the DIN jack, it will not be used in this application.
Continued on the next page
