Metra Electronics 99-7011 - Dash Disassembly; Initial Dash Panel Removal

1
3
MITSUBISHI LANCER 2008-2010
99-7011 DASH DISASSEMBLY
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Open the glove box and remove (1)
Phillips screw from the panel to the
right of the glove box door. Unclip
and remove the panel.
(Figure A)
Remove (1) Phillips screw from the
panel above the glove box then
unclip and remove the panel.
(Figure B)
Continued on page 2.
2
B
A
