MITSUBISHI LANCER 2008-2010
99-7011 DASH DISASSEMBLY
4
Unclip the radio switch panel includ-
ing the hazard switch assembly.
Unplug hazard switch assembly and
remove panel.
(Figure C)
5
Remove (4) Phillips screws secur-
ing the radio chassis. Unplug and
remove chassis.
7
Unclip assembly, unplug ribbon
cable from assembly and remove
assembly from the factory radio
panel. Retain screws and hazard
switch assembly for re-use during
kit preparation.
6
Remove (3) Phillips screws securing
the hazard switch assembly to the
factory radio switch panel. Unclip
and remove the switch.
(Figure D)
8
Unclip and remove the a/c vents
from the factory radio switch panel.
(Retain a/c vents for re-use during
kit preparation)
9
Remove and retain (7) factory clips
from rear of radio housing for
re-use during kit preparation.
Continue to kit prepar
ation.
