Metra Electronics 99-7011 - Double DIN Radio Provision; Stacked ISO Mount Units

99-7011 KIT ASSEMBLY
6
DOUBLE DIN RADIO PROVISION
STACKED ISO MOUNT UNITS PROVISION
Cut and remove the center bar from
the radio housing.
(Figure A)
1
Snap the Double DIN brackets to the
inside edge of the radio housing.
(Figure B)
2
Slide the Double DIN or stacked ISO
mount unit(s) into the bracket/radio
housing assembly and secure the
unit(s) to the assembly using the
screws supplied with the unit(s).
(Figure C)
3
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
A
B
C
Snap the Double DIN trim plate onto
the front of the radio housing.
(Figure C)
4
