99-7804B
Wiring Instruction
Connections to be made:
From the 14-pin black connector to the aftermarket radio:
• Connect the Orange wire to the illumination wire. (If the aftermarket radio has
no illumination wire, tape off the Orange wire).
The following wires are for aftermarket multimedia/navigation radios that
provide these wires (if not required, tape them off and disregard them):
• Connect the Light Green wire to the parking brake wire (if applicable).
• Connect the Blue/Pink wire to the speed sense wire (if applicable).
• Connect the Green/Purple wire to the reverse wire (if applicable).
If not equipped with a factory Rearview Camera and one wants to be added:
From the 22-pin black connector to the aftermarket radio:
• Connect the Yellow RCA to the aftermarket rearview camera (female to female
barrel connector may be needed depending on camera brand, not provided).
Note: If an aftermarket backup camera is connected it must be selected
in the Menu. (Menu button on SWC>Camera Settings>Backup Camera
Source>Aftermarket Backup Camera)
If Equipped with Factory Subwoofer:
From the 8-pin gray Honda connector to the aftermarket radio:
• Connect the White RCA to the “Subwoofer Output”
(a Y-RCA adapter may be needed, not provided).
ASWC-1 (if installing)
• After the interface is initialized, plug the ASWC-1 into the 12-pin harness
of the 7804 and refer to the ASWC-1 instructions.
Note: There are a couple harnesses in the vehicle that there will be no
harness connections; these are not needed in the installation.
• Green and Gray connectors with similar small square connectors.
• 20-pin, 18-pin, & 5-pin gray connectors.
