Metra Electronics 99-7861 - Dash Disassembly; Honda Pilot 2003-2008 Dash Removal

99-7861
1
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Using a small flat blade screwdriver
remove the blank plate from upper
right side of radio trim panel.
(Figure A)
2
HONDA PILOT 2003-2008
Unsnap radio trim panel. Unplug
switches and remove panel.
(Figure B)
3
Remove (4)10mm bolts securing
radio, unplug and remove radio.
(Figure C)
4
DASH DISASSEMBLY
A
B
C
