3
99-7861
Select the proper radio housing for
your vehicle. EX models use radio
housing (E) and LX models use radio
housing (L). The radio housings are
labeled on one of the mounting tabs.
(Figure A)
1
Mount the pocket to the back of the
radio housing with the (2) #8x3/8”
phillips pan head screws supplied.
(Notches on the pocket must be on
top.)
(Figure B)
2
Mount the rear support bracket to
the back of the pocket with the (2)
#8x3/8” Phillips truss head screws
supplied.
(Figure C)
3
KIT ASSEMBLY
A
B
C
HONDA PILOT
•2003-2008
•2006-2008
(Without Factory Navigation)
To Next Page
