2
99-7863
KIT ASSEMBLY
Slide
the DIN cage into the Radio
Housing and secure by bending
the metal locking tabs down.
(Figure A)
1
Slide the aftermarket radio into the
cage and secure.
(Figure B)
NOTE: Models equipped with factory
DDIN radio will require supplied O.E.
replacement panel.
(Figure C)
2
DIN HEAD UNIT PROVISION WITH POCKET
A
B
C
Continue to final assembly.
To Next Page
