99-7875/99-7875T DASH DISASSEMBLY
HONDA ACCORD 2008-10 / CROSSTOUR 2010
1
1
Unclip and remove the trim panel at
the left side of the factory radio.
( Figure B)
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
3
Unclip and remove the trim panel
from above the glove box at the right
side of the factory radio. ( Figure A)
2
Unclip and remove the top of the cen-
ter console including the cup holders.
( Figure D)
5
Remove (2) Phillips screws at the bot-
tom edge of the pocket assembly.
( Figure E)
6
Remove the (2) Phillips screws from
the left and right side of the of the
factory radio. (
Figure C)
4
Continue on page 2.
D
B
C
A
E
7
Remove (2) Phillips screws facing up
inside of the pocket below the factory
radio. ( Figure F)
Unclip and remove the pocket assem-
bly. ( Figure G)
8
