Metra Electronics 99-7875 - Double DIN;Stacked ISO Mount Units Provision

99-7875/99-7875T KIT ASSEMBLY
6
DOUBLE DIN/STACKED ISO MOUNT UNITS PROVISION
Cut and remove the center bar from
the Radio Housing. (Figure A)
1
Snap the Double DIN brackets to the
inside edge of the Radio Housing.
(Figure B)
2
Slide the Double DIN or stacked ISO
mount units into the bracket/radio
housing assembly and secure the
unit(s) to the assembly using the
screws supplied with the unit(s).
(Figure C)
3
Snap the Double DIN trim plate onto
the front of the Housing/Radio assem-
bly. (Figure C)
4
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
A
B
C
