Metra Electronics 99-7875 - ISO Mount Radio Provision with Pocket

99-7875/7875T KIT ASSEMBLY
5
A
B
C
ISO MOUNT RADIO PROVISION WITH POCKET
Mount the ISO Brackets to the radio
using the screws supplied with the
radio.
(Figure A)
1
Slide the radio into the Radio Housing
until it snaps into place. (Figure B)
2
Snap the Trim Plate onto the front of
the Radio Housing. (Figure C)
3
Snap the Pocket into the Radio
Housing.
(Figure C)
4
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
