MD 9225 Clamp Meter Series Operation
12
Temperature function
Be sure to insert the banana plug type-K temperature bead probe with correct
polarities. Slide-switch on defaults at degree C (Celsius). Press SELECT button
momentarily to select degree F (Fahrenheit). You can also use a plug adapter AMD
9024 (Optional purchase) with banana pins to type-K socket to adapt other type-K
standard mini plug temperature probes.
HOLD
The Hold feature freezes the display for later viewing. Press the HOLD button
momentarily to toggle to the Hold feature. The annunciator “ ” turns on.
MAX
The max feature compares and displays the measured maximum value as fast as 30ms
with auto-ranging capability. It allows the meter to capture in-rush currents in current
functions. Press and hold the MAX button for 1 second or more to toggle to the max
feature. The annunciators “MAX” and “ ” turn on.
