1) To reduce the risk of fire or electric
shock, do not expose this product to rain or
moisture. The meter is intended only for
indoor use.
To avoid electrical shock hazard, observe
the proper safety precautions when
working with voltages above 60 VDC or 30
VAC rms. These voltage levels pose a
potential shock hazard to the user.
Keep your hands/fingers behind the
hand/finger barriers (of the meter and the
test leads) that indicate the limits of safe
access of the hand-held part during
measurement. Inspect test leads,
connectors, and probes for damaged
insulation or exposed metal before using
the instrument. If any defects are found,
replace them immediately.
This Clamp-on meter is designed to apply
around or remove from uninsulated
hazardous live conductors. But still,
individual protective equipment must be
used if hazardous live parts in the
installation where measurement is to be
carried out could be accessible.
2) Hand/Finger Barrier to indicate the limits
of safe access of the meter during
measurement
3) Push-buttons for special functions &
features
4) Input Jack for all functions EXCEPT
non-invasive ACA & DCA current functions
5) Common (Ground reference) Input Jack
for all functions EXCEPT non-invasive
ACA & DCA current functions
6) Slide-switch Selector to turn the power
ON/OFF and Select a function
7) 3-3/4 digits 4000 counts LCD display
8) Jaw trigger for opening the clamp jaw
9) DCA direction for + polarity as well as
Jaw center Indicator, at where best ACA &
DCA accuracy is
