MPA-UPQ Splay Angles for Arrayed
Loudspeakers
The MPA-UPQ array adapter plate has six different M10
screw holes for adjusting the splay angle for arrayed
UPQ-1P loudspeakers. The following illustrations show the
possible splay angles for arrayed loudspeakers.
MPA-UPQ with Loudspeakers Arrayed at 50°
MPA-UPQ with Loudspeakers Arrayed at 46°
MPA-UPQ with Loudspeakers Arrayed at 42°
MPA-UPQ with Loudspeakers Arrayed at 38°
MPA-UPQ with Loudspeakers Arrayed at 34°
