7
CHAPTER 1: INTRODUCTION
HOW TO USE THIS MANUAL
Make sure to read these operating instructions in their
entirety before configuring a loudspeaker system with
UPQ-1P loudspeakers. In particular, pay close attention to
material related to safety issues.
As you read these operating instructions, you will encounter
the following icons for notes, tips, and cautions:
NOTE: A note identifies an important or useful
piece of information relating to the topic under
discussion.
TIP: A tip offers a helpful tip relevant to the topic
at hand.
CAUTION: A caution gives notice that an
action may have serious consequences and
could cause harm to equipment or personnel, or
could cause delays or other problems.
Information and specifications are subject to change.
Updates and supplementary information are available on the
Meyer Sound
®
website:
http://www.meyersound.com
Meyer Sound Technical Support is available at:
Tel: +1 510 486.1166
Fax: +1 510 486.8356
Email: techsupport@meyersound.com
INTRODUCING THE UPQ-1P LOUDSPEAKER
The self-powered UPQ-1P wide coverage loudspeaker is a
member of the popular UltraSeries
®
family of loudspeakers.
The UPQ-1P loudspeaker’s extended low-frequency head-
room gives it a smooth sound over a wide operating fre-
quency range of 55 Hz to 18 kHz. With its easy-to-use and
versatile QuickFly
®
rigging, the UPQ-1P loudspeaker is
equally suited to touring, rental, and fixed installation appli-
cations. High power-to-size ratio and ease of use make it an
outstanding performer in concerts and corporate AV appli-
cations, and ideal for venues such as theatres, houses of
worship, ballrooms, and clubs. The UPQ-1P loudspeaker
produces a peak output of 136 dB SPL with low distortion
as well as exceptionally flat phase and frequency response
in a compact, vented two-way, trapezoid enclosure.
The UPQ-1P loudspeaker offers an extremely consistent
polar response, and is distinguished by its constant-Q horn
that provides 80-degree horizontal by 50-degree vertical
coverage (-6 dB points) and a gentle coverage rolloff that
extends uniformly out to its -10 dB points of 100 by 60
degrees.
The smooth and consistent performance of the horn is the
result of meticulous research in Meyer Sound’s anechoic
chamber, and it exhibits a remarkably consistent beamwidth
in both the horizontal and vertical planes across a wide fre-
quency range of 1 kHz to 18 kHz. In addition, the UPQ horns
deliver uniform attenuation for all frequencies outside the
specified beamwidth.
UPQ-1P Wide Coverage Loudspeaker
