Meyer 7200 - Page 25

Model 7200 -25-
KEY PART NO. DESCRIPTION
1 918-0210-1-1 Yoke 1-3/4"-20 Splined
Assembly
2 918-0208-1-2 Grease Zerk in item 3
3 918-0208-1-3 Double Yoke
4 918-0208-1-4 Inboard Yoke
5 918-0208-1-5 Cross and Bearing Kit
6 918-0208-1-6 Spring Pin 10 x 80
7 918-0208-2-1 Cross and Bearing Kit
8 918-0208-1-14 Profile and Sleeve Wa
9 918-0208-2-2 Overrunning Clutch &
1bGA Profile Assy.
10 918-0208-2-3-1 Clamping Cone Bolt (In
-
cluded in Item 11)
11 918-0208-2-3 Cut Out Clutch
12 918-0208-2-4 Bearing Ring SC25
13 918-0208-2-5 Outer Shield Tube OVL
14 918-0208-1-7 Inner shield Tube Round
15 918-0208-1-8 CV Cone & Bearing Assy.
16 918-0208-1-9 Shield Cone 3 Rib
KEY PART NO. DESCRIPTION
17 918-0208-2-6 Shield Cone 8 Rib
18 918-0208-2-7 Safety Chain
19 918-0208-2-8 Decal Out-In Item 13
20 918-0208-1-10 Decal In-In Item 8
21 918-0208-2-9 Screw-In Item 15,16 & 17
22 918-0208-1-11 Support Bearing
23 918-0208-1-12 Zerk-In Item 8
24 918-0208-1-13 Cross and Bearing Kit
25 918-0208-2-10 Decal-K64
26 918-0210-1 1-3/4-20 Spline Tractor Half
Assembly
27 918-0208-2 1000 RPM Cutout Clutch Im
-
plement Half Assembly
28 918-0210-1-1-1 AS-Lock Kit For Item 1 (Inc.
Ring, Collar & Balls)
KEY PART NO. DESCRIPTION
1 918-0208-2-3-2 Housing
2 918-0208-2-3-3 Hub
3 918-0208-2-3-4 Spring Pack
4 918-0208-2-3-5 Washer
5 918-0208-2-3-6 Retaining Ring
6 918-0208-2-3-7 Sealing Ring
7 918-0208-2-3-1 Clamp Cone Assembly
8 918-0208-2-3-8 Cam
NS 918-0208-2-3-9 Bushing - In Item #2
918-0210 PTO DRIVE SHAFT ASSEMBLY
1000 RPM-20 SPLINE / 1-3/4” YOKE WWE2480 (80 DEGREE C.V.)
