Meyer 7200 - Unloading Gate and Gate Indicator

Model 7200 -41-
KEY PART NO. DESCRIPTION
1 955-0010 Hydraulic Cylinder-Center
Lift
2 55-0092 Street Elbow ½" M x 3/8"
Female
3 955-0010-1 3/8 x 28" Hydraulic Pipe
4 955-3605 3/8 x 90 Degree Elbow
5 955-3802-2 ½ x 3/8" Steel Hex Bushing
6 925-3754 Hydraulic Pipe Holder
Weldment
7 901-3713-2 Gate Indicator Pivot As
-
sembly
8 925-3755 Back Gate Assy.-Center Lift
(Prior to Serial
#SI057200201)
925-3764 Back Gate Assy.-Center Lift
w/Pin (Serial
#SI057200201 & Later)
9 901-3713-3 Indicator Linkage Arm
w/sleeve
10 925-3758-1 Front Cylinder Mount Plate
11 925-3757 Rear Cylinder Lift Plate
Weldment
12 949-3702 Poly Gate Seal
13 925-3729 Arm Pivot Shaft Assembly
14 925-3853 Pivot Arm Support
15 955-3754 3/4" Hose Tube Clamp
16 949-3701 Back Gate Slide Poly Slick
17 901-3706-9 Upper Back Gate Guide
Plate
18 925-13701-1 R. Cupped Material Guide
(Serial #SI067200308 &
Later)
19 925-13701-2 L. Cupped Material Guide
(Serial #SI067200308 &
Later)
20 925-3727 Rear Shield Mount Plate
21 925-3707 Gearbox Mount Strap
22 901-3701-20 Spinner Bearing Mount
Channel
23 901-3701-13 Gearbox Mounting Channel
24 901-3706-4 Outer Gate Guide Plate
25 925-3702 Corner Gearbox Mount
Plate
26 901-3853 Gearbox Mount Plate Gus
-
set
27 925-3743-1 Left Mount Plate Assembly
28 925-3743-2 Left Material Guide Assem
-
bly (Prior to serial
#SI067200308)
29 29-0009 Spring, Adjustment (Prior to
serial #SI067200308)
KEY PART NO. DESCRIPTION
30 925-3768-2 Spring Pivot Pin Assembly
(Prior to serial #SI067200308)
31 925-3768-3 Spring Shaft Assembly (Prior
to serial #SI067200308)
32 925-3768-4 Spring Pivot Sleeve Assembly
(Prior to serial #SI067200308)
33 815-1008-Z 1-8 Nylon Insert Locknut (Prior
to serial #SI067200308)
34 805-0010-Z 1" Flat Washer Zinc (Prior to
serial #SI067200308)
35 823-.18-1.25Z 3/16 x 1-1/4" Cotter Pin (Prior
to serial #SI067200308)
36 925-3744-1 Right Mount Plate Assembly
37 925-3744-2 Right Material Guide Assembly
(Prior to serial #SI067200308)
38 808-1.5-2.25-
10
1-1/2 ID X 2-1/4 OD X 10 Ga.
M.B. (Prior to serial
#SI067200308)
39 901-3720-4 R.H. Adj. Material Guide (Prior
to Serial #SI057200212)
40 901-3720-3 L.H. Adj. Material Guide (Prior
to Serial #SI057200212)
41 75-0413-1A Machine Bolt, Gr. 5, 1-14x4"
(Serial #SI067200308 & Later)
42 925-13803 Material Guide Linkage Arm
(Serial #SI067200308 & Later)
43 75-0304-1 LH Tie Rod Eye
44 75-0305-2 Jam Nut, 1-14, RH (Serial
#SI067200308 & Later)
45 827-2528-.38 Set Screw, 1/4-28x3/8" (Serial
#SI067200308 & Later)
46 75-0305-1 RH Tie Rod Eye (Serial
#SI067200308 & Later)
47 925-13804-1 Shear Sleeve (Serial
#SI067200308 & Later)
48 805-0050-Z Flat Washer, 1/2" (Serial
#SI067200308 & Later)
49 851-5013-3Z Machine Bolt, 1/2x3" Gr. 5
(Serial #SI067200308 & Later)
50 884-1014-Z Top Locknut, 1-14 (Serial
#SI067200308 & Later)
51 929-0003 Extension Spring (Serial
#SI067200308 & Later)
52 815-5013-Z Nylon Locknut, 1/2-13 (Serial
#SI067200308 & Later)
UNLOADING GATE AND GATE INDICATOR
