Model 7200 -26-
AUGER DRIVE THIRD REDUCTION
KEY PART NO. DESCRIPTION
1 925-3703 Front Bearing Plate Assy.
2 914-3808 2-1/4" Bearing 4-Bolt
3 910-0080 Sprocket Weldment 2-1/2"
Shaft, #80/120
4 851-7510-3Z 3/4-10 x 3" Machine Bolt
5 911-0063 #120-43 Pitch Chain
6 805-0075-Z 3/4" Flat Washer Zinc
7 912-0013 2" Nylon Roller Complete
7A 912-0013-1 2" Nylon Roller Only
7B 912-0013-2 Inner Sleeve
8 925-3895-1 #120 Chain Tightener
Weldment
9 925-3894-1 #120 Chain Tightener
Mount Weldment
KEY PART NO. DESCRIPTION
10 925-3822-6 2-Chain Link For Tightener
11 952-0001-3 Oil Brush Holder
12 952-0001-4 Oil Brush Holder
13 952-0001-6 Oil Brush Holder
14 952-0001-1-25 Oiler Brush Assembly
15 910-0081 Sprocket Weldment 2-1/2",
#120/140
16 933-3804 Eyebolt, 5/16 x 5" / 4"
Thread Length
17 929-3601 Extension Spring
18 14-0031 2"-4 Bolt Bearing
To Next Page
