Model 7200 -35-
KEY PART NO. DESCRIPTION
1 933-3701 3" Retaining Ring
2 910-0081 2-1/2" Auger Drive Sprocket Weldment
3 910-0071-1 140B35 3" 23 Spline Auger Sprocket (Prior to Serial # SI067200201)
910-0100 140B35 Shear Sprocket Assembly (Serial #SI067200201 & Later)
3A 831-5020-1.75 1/2-20 x 1-3/4" Allen Head Cap Screw Grade 8
3B 884-5020 1/2-20 Top Locknut Grade 8
3C 831-5618-1.75 9/16-20x1 ¾” Allen Head Cap Screw Grade 8
3D 884-5618 9/16-20 Top Locknut Grade 8
4 813-3118-Z 5/16" Regular Nut
5 933-3804 Eyebolt, 5/16 x 5" / 4" Thread Length
6 925-3766 Right/Left Auger Bushing Holder Assembly
7 913-3701 Nylon Bushing 3"ID x 4"OD x 3-3/8" Long
8 14-0031 2" Bearing 4-Bolt
9 808-.75-1.25-14 3/4"ID x 1-1/4"OD Machine Bushing 14 Ga.
10 912-0015 1-3/8" Nylon Roller Complete
10A 912-0015-1 1-3/8" Nylon Roller Only
10B 912-0015-2 Inner Sleeve
11 925-3716 #140 Right Auger Chain Tightener Bracket
12 929-3601 Extension Spring
13 911-0059 #140-46 Pitch Chain
14 851-7510-2Z 3/4-10 x 2" Machine Bolt Zinc
15 914-3807A 2-1/2" Round 4-Bolt Bearing
16 38-0013 5/16" x 1-3/4" Roll Pin
17 925-3822-6 2-Chain Link For Tightener
18 933-3710 Auger Sprocket Spacer 3.031ID x 3.5OD x 1"
19 925-3711 #140 Right Auger Chain Tightener Channel Assy.
20 30-0009 1/8" NPT Coupler
21 30-0016 1/8" NPT Close Nipple
22 30-0006 1/8" x 90 Degree Zerk
23 933-3704 Front Auger Washer Steel
24 933-3633 Copper Tube Grease Line 11" (Includes zerks, fittings)
25 933-3711 Shaft Spacer 14 GA x 3.062 x 3.500 Washer
RH AUGER DRIVE FINAL REDUCTION
