Model 7200 -47-
HUBS, AXLE & TANDEM ASSEMBLY
KEY PART NO. DESCRIPTION
1 75-0211 Hub Assembly Complete
15,000#
2 75-0211-2 Seal
3 75-0211-3 Bearing Cone
4 75-0211-4 Bearing Cup
5 75-0208-5 Bearing Cup
6 75-0208-6 Bearing Cone
7 75-0208-7 Washer
8 75-0208-8 Nut
9 75-0208-9 Cotter Pin
10 75-0208-10 Hub Cap
11 75-0208-11 Lug Nut - Flanged
12 75-0208-12 Stud Bolt
13 75-0211-1 Hub Only w/Races & Studs
14 75-0208-13 Hub Cap Bolt
15 75-0208-14 Hub Cap Gasket
16 30-0006 Zerk 1/8" NPT x 90 Degrees
17 901-3867-2 Tandem Locking Collar
18 881-5013-6.5 HHCS, ½-13 x 6-1/2" Gr. 8
19 814-5013-Z ½-13 Center Locknut
20 901-3873-3 Left O-Beam w/o Hubs
901-3873 Left O-Beam Complete
w/Hubs
KEY PART NO. DESCRIPTION
21 901-3874-3 Right O-Beam w/o Hubs
901-3874 Right O-Beam Complete
w/Hubs
22 901-3864-2 Pivot Shaft Nylon Bushing
23 901-3872 Tandem Axle Assembly
Only (Less O-Beams)
24 75-0269 Wheel Rim 12.25 x 22.5 x
10 Hole For Used
425/65/R22.5 Tire
75-0270 Wheel Rim SW18C x 16.1 x
10 Hole For 21.5 x 16.1 Tire
25 30-0002 1/8" NPT Straight Zerk
26 75-0111 3-1/2" Spindle Assembly
27 933-3626 Copper Tube Grease Line
31" (Includes zerks, fittings)
28 30-0009 1/8" NPT Coupler
29 30-0008 1/8" NPT Nipple
To Next Page
