Meyer 7200 - Corner Gear Reducer - Right Hand

Model 7200 -46-
CORNER GEAR REDUCER - RIGHT HAND
IMPORTANT!
USE #80-90 WT. GEAR LUBE OIL ONLY
.
DO NOT
USE GREASE FOR LUBRICANT.
OUTPUT
INPUT
KEY 1000 RPM DRIVE PART NO. 540 RPM DRIVE PART NO. DESCRIPTION
19-0036 19-0035 Complete Gearbox
1 19-0031-1 19-0031-1 Casting, Machined (Tapped Holes)
2 19-0031-2 19-0031-2 Casting, Machined (Thru Holes)
3 19-0036-1 19-0035-1 Assy, Cross Shaft/Gear
4 19-0031-4 19-0035-2 Assy, Pinion Shaft/Gear
5 19-0029-5 19-0029-5 Bearing Cone
6 19-0029-6 19-0029-6 Bearing Cup
7 19-0029-7 19-0029-7 Bearing Cone
8 19-0029-8 19-0029-8 Bearing Cup
9 19-0029-9 19-0029-9 Seal 1-3/4"
10 19-0029-10 19-0029-10 End Plug, Rubber Cover
11 19-0029-11 19-0029-11 Retaining Ring, 1.750
12 19-0016-11 19-0016-11 Bolt, 3/8-16 x 2.250 SHCS
13 19-0016-5 19-0016-5 Plug, ½ NPT
14 19-0023-2 19-0023-2 Bushing, ½ NPT to 1/8 NPT
15 19-0002-17 19-0002-17 Plug, Pressure Relief, 5 PSI
16 19-0031-5 19-0031-5 Dip Stick
17 19-0029-16 19-0029-16 Bearing Cone
