Model 7200 -29-
KEY PART NO. DESCRIPTION
1 925-3703 Front Bearing Plate As
-
sembly
1A 32-0018-1 Heavy Duty Latch
1B 32-0018-2 Keeper Latch
2 925-3706 Right Hand Front Support
3 924-3701 Right Front Shield Assem
-
bly
4 924-3702 Front Top Cover W/Hinges
& Latches
5 952-0001-3 Oil Brush Holder
6 925-3841 Outer Spring Tightener
Guide
7 29-0009 Compression Spring
8 925-3719 #140 Tightener Bracket As
-
sembly
9 808-.75-1.25-14 3/4"ID x 1-1/4"OD Machine
Bushing 14 Ga.
10 912-0008 #140 Reverse Idler Assem
-
bly W/Bearings
10A 910-0006-1 Bearing 3/4" ID x 2" OD
(2-Required)
11 925-3719-4 3/4-10 x 3-1/2" Machine
Bolt Lathed
12 925-3718 Side Shaft Tightener Arm
13 924-3702-3 Gas Shock Spacer/Hinge
Sleeve
14 933-3621 3/4-10 Jam Nut
15 912-0013 2" Nylon Roller Complete
15A 912-0013-1 2" Nylon Roller Only
15B 912-0013-2 Inner Sleeve
16 910-0015 80B18 Sprocket 1-1/2"
Bore, 3/8" Keyway
17 925-3705 Right Hand Top Side Sup
-
port
18 851-7510-3.5Z 3/4-10 x 3-1/2" Machine
Bolt Zinc
19 805-0075-Z 3/4" Flat Washer Zinc
20 911-0039 #80-107 Pitch Chain
21 923-3705 1-1/2" Front Side Shaft
KEY PART NO. DESCRIPTION
22 35-0010 3/8 x 3/8 x 1-1/2" Square
Key
23 925-3732 #140 Chain Tightener Bolt
Assembly
24 925-3731 #140 Chain Tightener Ad
-
justment Angle
25 808-150-300-10 10 Ga. X 1.5 I.D. x 3 O.D.
Machine Bushing
26 910-0036 80B24 Sprocket 1-1/2"
Bore, 3/8" Keyway
27 901-3701-36 #140 Chain Tightener Slide
Weldment
28 952-0001-1-25 Oiler Brush Assembly
29 925-3704 Left Hand Side Support
Plate
30 929-0003 Extension Spring
31 925-3822-6 2-Chain Link for Tightener
(Prior To SN SI067200252)
32 933-3804 Eyebolt, 5/16 x 5” / 4”
Thread Length
33 813-3118-Z 5/16” Regular Nut
34 952-0001-1-18 Oil Reservoir Two Quart
Tank
35 955-3703 Front Cover Gas Lift Assist
Spring
36 925-3734 Cover Spring Mount
Bracket
37 851-2520-2Z 1/4-20 x 2” Grade 5 Shear
Bolt
38 815-2520-Z 1/4-20 Nylon Insert
Locknut
39 33-0042 Manual Holder w/ Caps
FRONT SHIELD & SIDE SHAFT DRIVE
