Meyer 7200 - Page 31

Model 7200 -31-
KEY PART NO. DESCRIPTION
1 14-0031 2" Bearing 4-Bolt
2 851-2520-2Z 1/4-20 x 2" Grade 5
Shear Bolt
3 910-0058 2" Shear Sprocket
Weldment
4 815-2520-Z 1/4-20 Nylon Insert
Locknut
5 910-0054 Shear Sprocket Assembly
(1000 RPM)
910-0066 Shear Sprocket Assembly
(540 RPM)
5A 913-3602-2 2" I.D. x 2-1/4" O.D. x 2"
Bronze Bushing
6 808-2-3-14 2" I.D. x 3" O.D. x 14 Ga.
Machine Bushing
7 933-3702 2" Retaining Ring
8 925-3717-3 3/4-10 x 2" Machine Bolt -
Special
9 808-.75-1.25-14 3/4" I.D. x 1-1/4" O.D. x
14 Ga. Machine Bushing
10 912-0012 1-3/8" Nylon Roller Com-
plete
10A 912-0012-1 1-3/8" Nylon Roller Only
10B 912-0012-2 Inner Sleeve
11 925-3717 Tightener Arm Assembly
(1000 RPM)
925-3739 Tightener Arm Assembly
(540 RPM)
12 38-0013 5/16 x 1-3/4" Roll Pin
13 911-0060 #80-93 Pitch Chain (1000
RPM)
911-0061 #80-79 Pitch Chain (540
RPM)
14 929-0003 Extension Spring
15 925-3822-6 2-Chain Link For Tight
-
ener(Prior To SN
SI067200252)
16 933-3804 Eyebolt, 5/16 x 5" / 4"
Thread Length
17 813-3118-Z 5/16" Regular Nut
18 914-3602 1-1/2" Bearing, 4-Bolt
KEY PART NO. DESCRIPTION
19 910-0039 80B22 Sprocket 1-1/2"
Bore, 3/8" Keyway-10
RPM Auger Speed
910-0015 80B18 Sprocket 1-1/2"
Bore, 3/8" Keyway-8 RPM
Auger Speed
910-0077 80B28 Sprocket 1-1/2"
Bore, 3/8" Keyway-13
RPM Auger Speed (Stan
-
dard)
910-0036 80B24 Sprocket 1-1/2"
Bore, 3/8" Keyway-11
RPM Auger Speed
20 925-3601 Front Bearing Plate
21 931-3810 CV/OR PTO Shield As
-
sembly
22 901-3750-71 Rear Bearing Back Mount
Plate
23 933-3625 Copper Tube Grease Line
55" (Includes zerks, fit-
tings)
24 933-3627 Copper Tube Grease Line
12" (Includes zerks, fit-
tings)
25 923-3711 1-1/2" Input Drive Shaft /
Splined
26 35-0010 3/8 x 3/8 x 1-1/2"" Square
Key
27 933-3634 Copper Tube Grease Line
38" (Includes zerks, fit-
tings)
28 901-3750-72 Rear Bearing End Plate
Assembly
29 30-0006 1/8" NPT x 90 Degree
Zerk
30 30-0009 1/8" NPT Coupler
31 30-0016 1/8" NPT Close Nipple
32 910-0090 Reduction Sprocket
Weldment-Nonshear For
1000 RPM
(Serial #SI067200201 &
Later)
910-0091 Reduction Sprocket
Weldment-Nonshear For
540 RPM
(Serial #SI067200201 &
Later)
AUGER DRIVE FIRST REDUCTION
