Model 7200 -33-
KEY PART NO. DESCRIPTION
1 14-0031 2" Bearing 4-Bolt
2 851-2520-2Z 1/4-20 x 2" Grade 5 Shear Bolt
3 910-0058 2" Shear Sprocket Weldment
4 815-2520-Z 1/4-20 Nylon Insert Locknut
5 910-0054 Shear Sprocket Assembly (1000 RPM)
910-0066 Shear Sprocket Assembly (540 RPM)
5A 913-3602-2 2" I.D. x 2-1/4" O.D. x 2" Bronze Bushing
6 808-2-3-14 2" I.D. x 3" O.D. x 14 Ga. Machine Bushing
7 933-3702 2" Retaining Ring
8 851-7510-3Z 3/4-10 x 3" Machine Bolt Zinc
9 808-.75-1.25-14 3/4"ID x 1-1/4"OD Machine Bushing 14 Ga.
10 911-0041 #80-91 Pitch Chain
11 912-0013 2" Nylon Roller Complete
11A 912-0013-1 2" Nylon Roller Only
11B 912-0013-2 Inner Sleeve
12 925-3720 Second Reduction Tightener Arm Assembly
13 929-0003 Extension Spring
14 925-3822-6 2-Chain Link For Tightener (Prior To SN SI067200252)
15 813-3118-Z 5/16" Regular Nut
16 933-3804 Eyebolt, 5/16 x 5" / 4" Thread Length
17 910-0080 Second Reduction Sprocket Weldment 80/120
18 30-0009 1/8" NPT Coupler
19 30-0016 1/8" NPT Close Nipple
20 30-0006 1/8" NPT x 90 Degree Zerk
21 933-3643 Copper Tube Grease Line 53" (Includes zerks, fittings)
22 933-3632 Copper Tube Grease Line 36" (Includes zerks, fittings)
23 933-3640 Copper Tube Grease Line 21" (Includes zerks, fittings)
24 910-0090 Reduction Sprocket Weldment-Nonshear For 1000 RPM
(Serial #SI067200201 & Later)
910-0091 Reduction Sprocket Weldment-Nonshear For 540 RPM
(Serial #SI067200201 & Later)
AUGER DRIVE SECOND REDUCTION
